The 832 multifunction thermostat is compatible with hydronic heating, electric heating, and fan coil units. It has a narrow-edge refined appearance, supports six daily timed periods for energy saving, and has adjustable parameters. The insulated housing is suitable for high-power electric floor heating, with a built-in temperature calibration algorithm for accurate temperature measurement. It is equipped with an RS485 interface and supports centralized remote control.
Product Description
The 832 multifunction thermostat is compatible with hydronic heating, electric heating, and fan coil units. It has a narrow-edge refined appearance, supports six daily timed periods for energy saving, and has adjustable parameters. The insulated housing is suitable for high-power electric floor heating, with a built-in temperature calibration algorithm for accurate temperature measurement. It is equipped with an RS485 interface and supports centralized remote control.
Product Parameters
| Rated Load | AC220V/50Hz 3A |
| Power Consumption | ≤2W |
| Temperature Sensor Type | NTC 10K-3950 |
| Temperature Control Range | 5°C~45°C (can be modified to 5-99°C) |
| Temperature Measurement Accuracy | ±1°C |
| Resolution | 0.1°C |
Model Function Parameters
| Model | Load | Function |
|---|---|---|
| 832-3A | 3A | Hydronic Heating + Normally Closed Actuator |
| 832-3A-RS | 3A | Hydronic Heating + Timing Control + Normally Closed Actuator + RS485 Communication |
| 832-3A-W | 3A | Hydronic Heating + Timing Control + Normally Closed Actuator + WIFI |
| 832-30A | 30A | Electric Heating + Timing Control + External Sensor |
| 832-30A-RS | 30A | Electric Heating + Timing Control + External Sensor + RS485 Communication |
